Diagnostic

Software Features & Functionalities

In addition to the newest features provided by TOOLBOX PLUS mentioned above, the advanced diagnostic software provides the same great features users have come to expect:

• Displays both static and dynamic information from the system under test as well as both active and stored system faults
• Activates components to verify system integrity and correct component operation and installation wiring
• Provides access to repair documents, maintenance manuals and installation instructions
• Provides reverse Diagnostic Trouble Code (DTC) lookup
• Enables Aftermarket Programming for most pneumatic and hydraulic ABS ECUs
• Includes J1939 Bus Monitor for 500k Baud

Diagnostic Capabilities

Product Support

Tractor: SmartTrac® Stability Control Systems [Pneumatic ABS (mBSP, E8, E and D ECUs) and Electronic Braking System (EBS)], OnGuard® Collision Mitigation System, OnLane® and OnLaneALERT® Lane Departure Warning, OnSide® Blind Spot Detection, OptiRide® Electronically Controlled Air Suspension (ECAS), ECAS for Tractor (12V)

Trailer: ABS (iABS™, Enhanced Easy-Stop™ and Easy-Stop™), Roll Stability Support (RSS), TailGUARD™ Reversing Collision Avoidance System

Truck (Medium Duty), Bus and Motor Home Chassis: SmartTrac® Stability Control Systems (Hydraulic ABS, HABS-E version and Hydraulic Power Brake), ECAS for Buses (24V)

User Guide ->

We will download and install this sofware remotelly on your PC.
